NHS Diabetic Eye Screening Programme: grading definitions for referable disease

[ad_1]

Contains definitions for retinal screening images graded by the NHS Diabetic Eye Screening (DES) Programme. Images can be used for training purposes.

1. Classifying referable retinopathy

1.1 Feature based grading (FBG)

Graders identify individual features of diabetic retinopathy (DR) by selecting a given feature from the feature-based grading (FBG) form. This produces a grade which is determined by rules applied in the grading software.

1.2 Questionable features

Grading should be carried out in accordance with national guidance. Equipment should meet national specifications and used in line with recognised procedures for grading. This includes:

Microaneurysms should be differentiated from pigment spots by viewing in colour and red free and from artefacts by viewing on overlapping images where possible.

Intraretinal microvascular abnormality (IRMA) should not be recorded unless visible on colour images, without enlarging the image area, in addition to red free images.

1.3 Cotton wool spots

Isolated cotton wool spots (one or more) in the absence of any microaneurysm or haemorrhage should be counted as no DR (R0).

Any number of cotton wool spots (CWS) in the presence of other non‐referable features of DR should be graded as background DR (R1).

Where CWS are detected, graders should ensure they have checked for features of referable DR – in particular IRMA and early venous beading.

1.4 Venous loops

A venous loop should no longer be referred and should be regarded as a feature of R1.

1.5 Photocoagulation scars

Assign a P0 grade if no evidence of previous photocoagulation. Assign a P1 grade if evidence of previous photocoagulation (focal/grid to macula or peripheral scatter).

1.6 Definition of the macula

The macula is defined as the part of the retina which lies within a circle centred on the centre of the fovea. The radius is the distance between the centre of the fovea and the temporal margin of the disc.

2. Grading classification for pre‐proliferative DR (R2)

The grading classification for R2 is:

  • venous beading (venous beading from ischaemia in DR does not occur in isolation)
  • venous reduplication
  • multiple blot haemorrhages (MBH) (refer only in the presence of IRMA that are definitely seen if uncertain)
  • IRMA (check that they can still be seen on a colour image which has not been enlarged)

2.1 Venous beading

Refer people with venous beading. Venous beading from ischaemia in DR does not take place in isolation from MBH or IRMA.

2.2 Venous reduplication

Refer people with venous reduplication.

2.3 Multiple blot haemorrhages (MBH)

Refer people with MBH. If uncertain, refer only in the presence of IRMA that are definitely seen.

The MBH (previously known as MBH 3) images below shows the amount of haemorrhage present in the retina to warrant an R2 classification. An image which has this number of blot haemorrhages, or more, is referable.

The difficulties of counting blot haemorrhages are recognised. Most experts grade the MBH image set as having between 8 and 10 blot haemorrhages across both images.

2.4 Dot and blot haemorrhages

These haemorrhages are in the retina’s inner nuclear and outer plexiform layers. They are restricted in a particular location, and so take longer to clear than a superficial haemorrhage.

The difference between a dot and a blot is one of size. Blot haemorrhages are larger than the width of the smallest of the 4 branches of the central retinal vein as it crosses the edge of the disc. This is provided the veins are not very dilated.

Flame haemorrhages are superficial haemorrhages in the nerve fibre layer. Any haemorrhage that is flame shaped or any MA should not be counted as a blot.

MBH macula

MBH nasal

2.5 Intraretinal microvascular abnormality (IRMA)

People with IRMA should be referred. Only IRMAs that are definitely seen should be classified as R2.

If an IRMA is found, the grader should return to the colour image. IRMA is considered present if the IRMA can still be seen on the colour image, that has not been enlarged, as well as on the red free.

If an IRMA can only be seen on a red free image and not on the colour image a referral should not be made (returned to annual screening).

The above assumes screen settings, colour balance, monitor, software and camera settings are optimal according to the recommendations of the NHS DES Programme.

Sometimes collaterals from vein occlusions can look like IRMAs. In cases where there is a localised patch of possible IRMA, the likelihood of a vein occlusion should be considered. If it is judged that small collaterals are present from an old vein occlusion rather than IRMA, this should not be given an R2 grade.

There are 3 examples of IRMA images below.

IRMA 1

IRMA 2

IRMA 3

3. Grading classification for proliferative DR (R3)

The new classification consists of 2 categories – R3A (active proliferative retinopathy) and R3S (stable treated proliferative retinopathy).

This allows for urgent attention where disease is active. It also helps maintain a high quality monitoring pathway outside the hospital eye service (HES) for discharged people once treatment has allowed the condition to stabilise.

3.1 R3A

People should be classified as R3A (active) when:

  • they have newly presenting proliferative retinopathy
  • previous treatment has not been deemed stable by the treating ophthalmologist
  • new features indicating reactivation of proliferation or potentially sight threatening change from fibrous proliferation can be seen with respect to a previously obtained reference image set

3.2 R3S

R3S (stable) is when there is:

  • evidence of peripheral retinal laser treatment
  • a stable retina with respect to reference images taken at or shortly after discharge from HES

A referral outcome grader (ROG) will always be responsible for the decision as to whether the presentation can be considered stable. They may make that decision based on photography and patient history when encountering people who have moved from other screening services.

A referral should be made as R3A in any case where there is doubt.

3.3 Pathway

On discharge, the HES must either:

  • place a benchmark set of images on the screening service software
  • supply a benchmark set of images electronically for the service to import
  • arrange for a set of benchmark images to be taken by the screening service within 3 months

These should be graded by the discharging clinician to make sure they represent a stable condition.

When the individual is screened again, their images must be compared with the benchmark images taken on discharge before deciding the grade.

People who are graded as R3S following discharge from the HES should be managed in the DS pathway.

People with stable treated retinopathy currently in routine annual screening should:

  • be graded as R3S at their next routine annual screen
  • have benchmark images taken
  • be transferred to DS pathway for their next and subsequent routine appointments

The only R grades that will be allowed for such people are R3A and R3S

The grading would be R3S if there are no significant changes from the baseline discharge images.

If there are significant changes then the patient would revert to R3A and be urgently referred back to the HES. Not all changes will be clinically urgent but the grading committee decided it is better to keep things simple and not introduce the concept of routine referral of R3.

Significant changes requiring urgent re-referral would include:

  • signs of active neovascularisation (including active new vessels)
  • pre-retinal or vitreous haemorrhage

4. Grading classification for maculopathy – groups of exudates (M1)

A group of exudates is an area of exudates that is greater than or equal to half the disc area and all within the macular area.

4.1 How to work out the area

The outer points of the exudates are joined and compared to half the area of the optic disc.

4.2 Referable groups of exudates

In this section you’ll find examples of referable and non-referable groups of exudates.

The example below (GE1) would not be referred. This is an image showing an area of exudates that is less than half a disc.

GE 1

The example below (GE2) would not be referred. This is an example of an area of exudates that is less than half a disc area, borderline in size, but less than half a disc within the macular area.

GE 2

The example below (GE3) would be referred. This is an example of an area of exudates that is greater than half a disc.

GE 3

The example below (GE4) would also be referred. This is an example of an area of exudates that is greater than half a disc.

GE 4

There will be cases when the VA is less than or equal to 6/12 and microaneursms or haemorrhages present within one-disc diameter of the centre of the fovea.

If screener has documented known amblyopia, or there is AMD which may also show exudates within the macula to account for the poor VA:

  • the images should be graded by the ROG
  • decide whether the reduced vision is due to the amblyopia, the AMD or diabetic maculopathy

If the ROG decides the reduced vision is due to the amblyopia or AMD, the maculopathy should be graded as M0. Follow local protocols for referral of non-DR lesions.

If the ROG decides that the reduced VA could be caused by diabetic maculopathy, grade the maculopathy as M1 and refer the person in accordance with the nationally recommended pathway.

6. Early treatment DR study (ETDRS) final retinopathy severity scale

6.1 No apparent retinopathy

ETDRS (final) grade: 10, 14 and 15

Lesions: DR absent DR questionable

Risk of progression to PDR in 1 year (ETDRS interim): N/A

ETDRS screening or clinic follow up intervals: N/A

English Screening Programme levels: R0 currently screen annually

Scottish Grading Classification: R0 currently screen annually

6.2 Mild NPDR (1)

ETDRS (final) grade: 20

Lesions: micro aneurysms only

Risk of progression to PDR in 1 year (ETDRS interim): N/A

ETDRS screening or clinic follow up intervals: 1 year

English Screening Programme levels: R1: screen annually. Background microaneurysms, retinal haemorrhages, any exudate

Scottish Grading Classification: R1: screen annually. Background dot haemorrhages microaneurysms, hard exudates cotton wool spots, blot haemorrhages superficial or flame shaped haemorrhages

6.3 Mild NPDR (2)

ETDRS (final) grade: 35a, 35b, 35c, 35d, 35e

Lesions: One or more of the following: venous loops > definite in 1 field SE, IRMA, or VB questionable. Retinal haemorrhages present HE > definite in 1 field SE > definite in 1 field

Risk of progression to PDR in 1 year (ETDRS interim): Level 30 = 6.2%

ETDRS screening or clinic follow up intervals: 4 to 6 months

English Screening Programme levels: R1: screen annually. Background microaneurysms, retinal haemorrhages, any exudate

Scottish Grading Classification: R1: screen annually. Background dot haemorrhages microaneurysms, hard exudates cotton wool spots, blot haemorrhages superficial or flame shaped haemorrhages.

6.4 Moderate NPDR

ETDRS (final) grade: 43a, 43b

Lesions: H/Ma moderate in 4 to 5 fields or severe in 1 field or IRMA definite in 1 to 3 fields (ETDRS: Grade 0 = no evidence of IRMA. Grade 1 = questionable IRMA. Grade 2 = IRMA present < standard photo 8A. Grade 3 = IRMA present > standard photo 8A but < standard photo 8B. Grade 4 = IRMA > standard photo 8B)

Risk of progression to PDR in 1 year (ETDRS interim): Level 41 = 11.3%

ETDRS screening or clinic follow up intervals: 3 to 6 months

English Screening Programme levels: R2: refer to ophthalmologist. Pre-proliferative MBH IRMA venous beading, venous reduplication. It is recommended that venous loop is removed

Scottish Grading Classification: R2 Background DR BDR – observable. Rescreen 6 months. 4 or more blot haemorrhages (in other words: AH standard photograph 2a – in one hemi-field only)

6.5 Moderately severe NPDR

ETDRS (final) grade: 47a, 47b, 47c, 47d

Lesions: Both level 43 characteristics – H/Ma moderate in 4 to 5 fields or severe in 1 field and IRMA definite in 1 to 3 fields or any one of the following: IRMA in 4-5 fields, HMA severe in 2-3 fields, VB definite in one field

Risk of progression to PDR in 1 year (ETDRS interim): Level 45 = 20.7%

ETDRS screening or clinic follow up intervals: 4 months

English Screening Programme levels: English DES Programme referral criteria.

Scottish Grading Classification: R3 Background diabetic retinopathy (BDR) – referable. Any of the following features: 4 or more blot haemorrhages (in other words, AH standard photograph 2a – in both inferior and superior hemi-fields, venous beading standard photograph)
